Table of Contents
o nt e e n o nt e e n o nt e e n o nt e e n
(S. 8)
(S. 8)
(S. 8)
(S. 8)
(S. 10)
(S. 11)
(S. 11)
(S. 11)
(S. 11)
(S. 12)
(S. 12)
(S. 12)
(S. 13)
(S. 14)
(S. 16)
Starting characteristics
(S. 16)
First start
(S. 16)
Restart
(S. 16)
System Configuration
(S. 16)
Configuration of the pressure transmitters
(S. 17)
Low pressure transmitter Z2 (LP-Z2)
(S. 18)
Low-pressure Regulation
(S. 18)
Control algorithm for LP control
(S. 18)
Control algorithm with LP step controller
(S. 19)
Neutral zone with compressor step control
(S. 19)
Compressor switching times for compressor step regulation
(S. 19)
Control algorithm with LP combined control
(S. 20)
Switching on / switching off of fixed-speed compressors
(S. 20)
Loading / unloading of fixed-speed compressors during operation with capacity-controlled compressors.
(S. 21)
Speed increase for purpose of oil lubrication
(S. 24)
Setpoint shift
(S. 24)
Setpoint shift via room temperature / jump to end of the metadata
(S. 24)
Setpoint shift - demand-dependent via consumer
(S. 25)
Setpoint shift via CAN bus
(S. 25)
Setpoint shift via external analogue signal
(S. 25)
Setpoint shift via humidity sensor
(S. 26)
Base load rotation
(S. 27)
Base load rotation for speed controlled compressors
(S. 27)
Load shedding
(S. 28)
Emergency power mode
(S. 29)
High-pressure regulation
(S. 30)
Control of high pressure control valve
(S. 30)
Neutral zone HP control
(S. 30)
HP valve control for stopped compressors
(S. 30)
Limitation of the HP valve opening degree by the medium pressure
(S. 30)
High pressure setpoint calculation
(S. 31)
HP regulation setpoint calculation in normal operation
(S. 31)
HD regulation setpoint calculation in HRC mode
(S. 31)
Gas cooler outlet temperature regulation
(S. 31)
Neutral zone fan control
(S. 32)
Control algorithm for fan control
(S. 32)
Control algorithm with step controller
(S. 32)
Switching modes for step control
(S. 32)
Regulation of the fan speed with continuous control
(S. 34)
Control algorithm for parallel combined control type of control
(S. 35)
Control algorithm for stages combined control type of control
(S. 36)
Gas cooler package with integrated outdoor evaporator in bypass operation
(S. 37)
Gas cooler package with ebmpapst fans
(S. 38)
Setpoint calculation tG
(S. 43)
Setpoint calculation in normal operation
(S. 43)
Setpoint calculation in HRC mode
(S. 44)
Switching times of the fans
(S. 44)
Setpoint increase tG
(S. 45)
Protection and base load rotation of the fan motors
(S. 45)
Medium pressure regulation
(S. 45)
Regulation
(S. 46)
Medium pressure shift / monitoring of minimum superheat
(S. 46)
Setpoint reduction above medium pressure
(S. 48)
Medium pressure maintenance
(S. 48)
Medium pressure maintenance via pressure maintenance valve
(S. 48)
Medium pressure maintenance by opening the HP valve
(S. 49)
ECO operation
(S. 49)
Control by a VS 3015 C
(S. 50)
Control by a VS 3015 C and a separate pack controller
(S. 53)
LT compressor in booster operation
(S. 55)
Regulation of the minimum superheat using a hot gas bypass valve
(S. 57)
Regulation of the maximum superheat using the suction gas injection valve
(S. 58)
Monitoring
(S. 59)
Safety chain
(S. 59)
Monitoring of differential oil pressure switch / compressor high pressure limiter
(S. 60)
Monitoring of the compressor motor overload cut-out
(S. 60)
Cylinder head temperature monitoring
(S. 61)
Low pressure monitoring
(S. 62)
High pressure monitoring
(S. 63)
Monitoring of the medium pressure
(S. 65)
Monitoring of the medium pressure valve
(S. 65)
Monitoring of the fan motor overload cut-out
(S. 65)
Monitoring of the fan speed controller
(S. 66)
Monitoring of the compressor speed controller
(S. 67)
External alarm monitoring
(S. 68)
Monitoring of the switching frequency
(S. 69)
Refrigerant monitoring
(S. 70)
Monitoring of the fast unload / External Off
(S. 70)
Rupture disk monitoring
(S. 70)
Setpoint switching
(S. 70)
Ambient data for the setpoint switching
(S. 71)
Consumer lockout
(S. 71)
Spray system control
(S. 72)
COP monitoring
(S. 74)
COP optimisation
(S. 74)
Operating data and archiving
(S. 75)
Operating hours of compressors and fans
(S. 75)
Daily run times, switching pulses and switch-on rates
(S. 75)
Capacity-controlled compressors
(S. 75)
Oil balancing
(S. 76)
Installation and start-up of VS 3015 C
(S. 78)
DIN rail mounting
(S. 79)
Requirements for the activation of NT CO2 operation (transcritical)
(S. 79)
Basic hardware settings
(S. 79)
SIOX extension module - for DIN rail mounting
(S. 81)
Connection of the SIOX modules to the pack controller
(S. 82)
Basic settings with S1
(S. 83)
Setting the CAN bus address with S2
(S. 84)
Setting of the interface RS485/TTY using jumper J1
(S. 85)
Setting of the interface of the internal SIOX using jumper J2
(S. 85)
Configuration of the analogue inputs and outputs at the factory
(S. 85)
Power Supply
(S. 86)
Status LEDs
(S. 88)
Basic parameter settings
(S. 89)
Start-up of speed-controlled condenser fans / compressors
(S. 90)
Procedure for the start-up of a system
(S. 91)
Commissioning fan control via Modbus
(S. 93)
Battery replacement
(S. 95)
Firmware Update
(S. 97)
Installation of the update software on the PC
(S. 97)
Update of the current firmware
(S. 98)
Connection and terminal assignment of VS 3015 C
(S. 102)
Connector pin assignments for the VS 3015 C basic module
(S. 103)
Terminal Diagrams for Basic Module and SIOX
(S. 104)
Terminal Assignment of the 230 V AC Power Supply
(S. 104)
Terminal Assignment of the Dgital Inputs - 230 V AC
(S. 105)
Terminal Assignment of the Relay Outputs 230 V AC
(S. 109)
Terminal Assignment of the Analogue Inputs
(S. 112)
Terminal assignment of the analogue outputs
(S. 115)
CAN bus, SIOX and Modbus (ebmpapst fans) terminal assignment
(S. 117)
Operating modes of VS 3015 C
(S. 120)
Manual / automatic emergency mode selection
(S. 120)
Service Mode
(S. 121)
Display of the operating states
(S. 121)
Operation of VS 3015 C
(S. 122)
Operation possibilities
(S. 122)
Remote control using a terminal
(S. 122)
Menus and operating screens
(S. 124)
Call controller menu using remote operation
(S. 126)
CI 4x00 System Centre - Remote control
(S. 127)
CI 3x00 store computer / AL 300 operator terminal - remote control
(S. 127)
Deactivating the input lock
(S. 128)
CI 4x00 system centre - login and logout
(S. 128)
CI 3x00 store computer / AL 300 operator terminal - unlock
(S. 129)
Activating service mode
(S. 129)
CI 4x00 system centre service mode
(S. 129)
CI 3x00 store computer - service mode
(S. 129)
Menu structure of VS 3015 C
(S. 131)
Menu tree
(S. 131)
Menu 0 Main menu
(S. 132)
Menu 1 Summary
(S. 133)
Menu 2 Actual values
(S. 133)
Menu 3 Setpoints
(S. 136)
Menu 4 Clock
(S. 162)
Menu 5 Messages
(S. 162)
Menu 6 Operating data
(S. 163)
Menu 7 Basic settings
(S. 165)
Menu 8 Service Mode
(S. 165)
Decommissioning and disposal
(S. 167)
Decommissioning / Dismantling
(S. 167)
Disposal
(S. 167)
Alarms and messages VS 3015 C
(S. 168)
Message system
(S. 168)
Structure of the messages
(S. 168)
Automatic Prioritisation
(S. 169)
Overview of all alarms and messages
(S. 169)
Technical Data VS 3015 C
(S. 172)
Electrical Data VS 3015 C
(S. 172)
Mechanical Data VS 3015 C
(S. 174)
Versions
VS 3015 C
Betriebsanleitung - 16.05.2023 13:34
VS 3015 C
Operating instruction - 16.05.2023 13:34
Show advanced options
Link to preview page in EDP
Link to file directly
User language settings (browser settings)
English
German
French
Newest version
:
VS 3015 C<br />Betriebsanleitung
:
VS 3015 C<br />Operating instruction
This qr-code refers to shown link.
Read metadata
Generate preview images of pages
Generate links
Update in search index
Benachrichtigung nochmal versenden
Enter one or more users
Grant rights to a group
Prospect
Customer
Internal
Notify users about additional grants?
Send copy of notifications to me
Share
Grant access
