Description / Table des matières
Conventions
E
Explanation of 'Safety Instructions and Hazard Warnings'
Warning Signs and Symbols Employed
1 Safety instructions
Disclaimer in the event of non-compliance
Personnel requirements, requirements on staff
Intended use
BGV A3 - Five safety rules
Electrostatic sensitive devices (ESDs)
ESD - Rules for handling and working
Abbreviations used
2 System Design of UA 410 L
Application
Hardware
New features compared to previous versions
3 Application of UA 410 L
Versions
Controller type
Version update
4 Function of UA 410 L
Selection of the temperature sensors
Required and optional sensors
Controller function
Cooling (solenoid valve)
Temperature control (with recording)
Emergency operation
Temperature recording
Defrosting
Monitoring
Archiving operating data
Temperature recording to EU Regulation 37/2005
Temperature recording to EU Regulation DIN EN 12830
Real time clock
Temperature display BT 30
Offset for temperature display
Connecting BT 30 Temperature Display
5 Installation and Startup of UA 410 L
Installation
DIN rail mounting of the Temperature Data Logging Controller
Mounting on the DIN rail
Disassembling from the DIN rail
Handling of the spring terminals
Basic configuration
Setting CAN bus address
Setting the controller type
Terminal assignment for 230 V AC power supply
Status LEDs
Basic configuration of the controller
Naming of the controller
Restart - restart of the controller
First start / reset controller to factory settings
Maintenance and battery replacement
Firmware Update
Firmware Update requirements
Uploading the firmware update
Rectification of driver problems
6 Pin and Terminal Assignments of UA 410 L
Terminal diagram
Terminal assignment of the 230 V AC power supply
Terminal assignment of the 230 V AC relay outputs
Mode of operation of the relay and transistor outputs
Terminal assignment of the 230 V AC digital inputs
Terminal assignment of the 0..10 V analogue outputs
Terminal assignment of the CAN bus
Terminal assignment of the 24 V DC transistor outputs
Terminal assignment of the DISPLAY interface
Terminal assignment of the 4..20 mA analogue inputs
Terminal assignment of the analogue inputs of temperature sensors
Terminal assignment of the USB interface
Terminal assignment of the CI 320/TTY interface
7 Operation of UA 410 L
Operation possibilities
Local operation with a BT 300 x operator interface
Lock-down of the setpoint change
Remote control via a terminal
Menus and operating screens
Calling the controller menu via remote control
System Centre CI 4x00
Store computer CI 3x00 / operator terminal AL 300
Deactivating the input lock-down
System centre CI 4x00
Store computer CI 3x00 / operator terminal AL 300
Activating service mode
System centre CI 4x00
Store computer CI 3x00
8 Menu Structure of UA 410 L
Controller type UA 410 L – Menu tree (Rx.1 to Rx.0)
Menu 0 Main menu
Menu 1 Actual Value
Menu 2 Setpoints
Menu 3 Clock
Menu 4 Messages
Menu 5 Archive
Menu 6 Configuration
9 Decommissioning and disposal
Decommissioning / Demounting
Disposal
10 Alarms and Messages of UA 410 L
Alarm signaling and monitoring
High or low temperature alarm
Disabling high or low temperature alarm
No defrost alarm
Sensor break alarm
Hardware fault alarm
Alarm routes
Messages
Transient alarms and messages
Message log
11 Specifications of UA 410 L
Electrical data
Mechanical data of the controller
Mechanical data of the temperature sensor L243 / 5K3A1
12 Order numbers and accessories of UA 410 L
Case Controller
Accessories
Versions
