Table of Contents
1 About this document
1.1 outubeAbout the product
1.1.1 Manufacturer and designations
1.1.2 Performance specification
1.1.3 Designation code for E°Motors
1.1.4 Overview of the motor series
1.2 Contents of this document
1.3 Target audience
1.4 Disclaimer of liability
1.5 Conventions
1.6 Explanation of warning statements
1.6.1 Structure
1.6.2 Warning signs
1.7 Additional documents of reference
1.8 Standards compliance and conformity
1.8.1 EU declaration of conformity
1.8.2 UL listing and compliance
2 Safety information and precautions
2.1 Intended use and operating conditions
2.1.1 Intended use
2.1.2 Ambient conditions
2.1.3 Information on cooling
2.2 Personnel qualification requirements
2.2.1 Qualified personnel
2.2.2 Special skills
2.3 General safety precautions and hazards
2.3.1 General safety precautions
2.3.2 How to behave in a dangerous situation
2.3.3 Safety rules for electric equipment
2.3.4 Specific hazards
2.3.5 In case of fire
3 Technical data: E°SL motors (400 V)
3.1 General technical data (E°SL motors)
3.2 E°SL-028…
3.2.1 Dimensions
3.2.2 Technical data
3.3 E°SL-036…
3.3.1 Dimensions
3.3.2 Technical data
3.4 E°SL-056…
3.4.1 Dimensions
3.4.2 Technical data
3.5 E°SL-063…
3.5.1 Dimensions
3.5.2 Technical data (E°SL-063-04.../-06...) . d ic ch ec e ec e e e
3.5.3 Technical data (E°SL-063-08.../-10...)
3.6 E°SL-071...
3.6.1 Dimensions
3.6.2 Technical data (E°SL-071-12.../-20...)
3.6.3 Technical data (E°SL-071-26...)
3.7 E°SL-100…
3.7.1 Dimensions
3.7.2 Technical data
4 Technical data: E°SM motors (400 V)
4.1 General technical data (E°SM motors)
4.2 E°SM-036…
4.2.1 Dimensions
4.2.2 Technical data
4.3 E°SM-056…
4.3.1 Dimensions
4.3.2 Technische Daten
4.4 E°SM-063…
4.4.1 Dimensions
4.4.2 Technical data
4.5 E°SM-071…
4.5.1 Dimensions
4.5.2 Technical data
4.6 E°SM-132…
4.6.1 Dimensions
4.6.2 Technical data
5 Technical data: E°SX motors (400 V)
5.1 General technical data (E°SX motors)
5.2 E°SX-063…
5.2.1 Dimensions
5.2.2 Technical data
6 Technical data: E°SY motors (400 V)
6.1 General technical data (E°SY motors)
6.2 E°SY-065…
6.2.1 Dimensions
6.2.2 Technical data
7 Technical data: E°SZ motors (400 V)
7.1 General technical data (E°SZ motors)
7.2 E°SZ-028...
7.2.1 Dimensions
7.2.2 Technical data
7.3 E°SZ-071...
7.3.1 Dimensions
7.3.2 Technical data
8 Technical data: E°SL3 motors (230 V)
8.1 General technical data (E°SL3 motors)
8.2 E°SL3-020…
8.2.1 Dimensions
8.2.2 Technical data
8.3 E°SL3-030…
8.3.1 Dimensions
8.3.2 Technical data
8.4 E°SL3-036-…
8.4.1 Dimensions
8.4.2 Technical data
8.5 E°SL3-056…
8.5.1 Dimensions
8.5.2 Technical data
8.6 E°SL3-063…
8.6.1 Dimensions
8.6.2 Technical data
9 Technical data: E°SM3 motors (230 V)
9.1 General technical data (E°SM3 motors)
9.2 E°SM3-028…
9.2.1 Dimensions
9.2.2 Technical data
9.3 E°SM3-063…
9.3.1 Dimensions
9.3.2 Technical data
10 Technical data: E°SU3 motors (230 V)
10.1 General technical data (E°SU3 motors)
10.2 E°SU3-030…
10.2.1 Dimensions
10.2.2 Technical data
10.2.3 Torque characteristics
10.3 E°SU3-040…
10.3.1 Dimensions
10.3.2 Technical data
10.3.3 Torque characteristics
10.4 E°SU3-055…
10.4.1 Dimensions
10.4.2 Technical data
10.4.3 Torque characteristics
11 Technical data: E°SCL motors (48 V)
11.1 General technical data (E°SCL motors)
11.2 E°SCL-030...
11.2.1 Dimensions
11.2.2 Technical data
11.2.3 Torque characteristics
12 Technical data: E°SCX motors (48 V)
12.1 General technical data (E°SCX motors)
12.2 E°SCX-020...
12.2.1 Dimensions
12.2.2 Technical data
12.2.3 Torque characteristics
12.3 E°SCX-030...
12.3.1 Dimensions
12.3.2 Technical data
12.3.3 Torque characteristics
13 Connections
13.1 Power connections
13.1.1 E°SL, E°SM, E°SX, E°SY, E°SZ motors
13.1.2 E°SL3, E°SM3, E°SU3 motors
13.1.3 E°SCL, E°SCX motors
13.2 Feedback connections
13.2.1 E°SL, E°SM, E°SX, E°SY, E°SZ motors
13.2.2 E°SL3, E°SU3 motors, E°SL, E°SX motors
13.2.3 E°SCL, E°SCX motors
14 Decommissioning and disposal
14.1 Disassembly
14.2 Disposal
